DWARF 412-RGBL is a 12×15 watts multi-chip RGBL, LED Exterior wash. It adopts a new quad LED chips, inserted with smart temperature control system, performing high color saturation and outstanding color mixing. Employing creative digital lighting dimming technology and a flexible segment control system, the fixture makes the perfect artistic lighting effect.
SOURCE:
- Light source: 12×15 watts multi-chip RGBL
- LED life expectancy: 50,000 Hrs
- Peak Intensity: 75000 cd (15°)
OPTICAL SYSTEM
- Optics: 15°
- Light output: 18,500 Lux @2m @15°
CONTROL & PROGRAMMING
- Control Protocols: DMX, RDM
- DMX control channels: 0-100%
- Controllable sections: 3
- Color Mixing: RGBL
ELECTRICAL
- Input Voltage: AC100-240V, 50/60Hz
- Max Power: 200 W
- Power Factor: > 0.9
CONNECTIONS
- Power connection: 3m cable (input only)
- Data connection: 3m cable (input + output)
PHYSICAL
- Dimensions: 530 x 200 x 313mm
- Net Weight: 12kg
- Color: Off-white (Gray, Black Optional)
- Housing: Die-cast aluminum
- IP Rating: 66
- Operation temperature: – 40°C~45°C (operating) /- 20°C~45°C (startup)
