ROD 124-C

ROD 124-C is a seamless 24×3 watts Cool White linear wash.It is a per-fectly designed fixture with a length of 610 millimeters, power supply and driver built- in lamp body, integrated power and DMX signal cable. Flexible lighting device for application in a variety of building structures.

SOURCE

• Light source: 24×3 watts Cool White
• LED life expectancy: 50,000 Hrs
• Peak Intensity: 30202 cd (15°)

OPTICAL SYSTEM

• Optics: 15° (25°, 30°,60°, 15°x30°, 60°x15°)
• Light output: 7,700 Lux @2m @ 15°

CONTROL & PROGRAMMING

• Control Protocols: DMX 512, RDM
• Dimmer: 0%-100% 16 Bit
• DMX control channels: 0-100%
• Dimmer: 0%-100% 16 Bit
• Controllable sections: 1
• Color: Cool white

 ELECTRICAL

• Input Voltage: AC100-240V, 50/60Hz
• Max Power: 40 W
• Power Factor: > 0.9
• Built-in power supply

CONNECTIONS

• Power connections: Integrated power and signal cable

PHYSICAL

• Dimensions: 610x62x84 mm
• Net Weight: 2.4 kg
• Color: Silver
• Housing: Extruded aluminium
• IP Rating: 66
• Operation temperature: – 40°C~45°C (operating) /
  – 20°C~45°C (startup)
