SPR 328R

SPR 328R

3 pin Rack Mounted RDM/DMX Splitter

SPR 328R is a 1U 19” Rack mounted RDM/DMX Splitter. It buffers, multiplies, isolates and protects console DMX outputs. It features 2 independent RDM/DMX inputs/thru and 8 optically isolated RDM/DMX outputs, where each can be assigned to one of the two inputs giving flexibility in data distribution.

SKU: SPR328R Category:


  • Bi-directional communication and data transfer Split and boost the RDM/DMX signal
  • Power and data optically isolated RDM/DMX ports
  • High voltage protection
  • Selectable input source for each RDM/DMX output High brightness power and RDM Status LED indicators Individual input selection LED indicators per output
  • Front panel power On/Off switch


  • RDM/DMX Pass-Thru
  • Input selector switches
  • Power On/Off switch
  • Power and data LED indicators


  • Data inputs: 2 x Neutrik 3 pin XLR
  • Data thru: 2 x Neutrik 3 pin XLR
  • Data outputs: 8 x Neutrik 3 pin XLR
  • Power input: Neutrik powerCon
  • Power output: Neutrik powerCon


  • Input voltage: AC 88-256V 50/60Hz


  • Dimensions: 482 x 118 x 46mm
  • Net weight: 1.7 Kg
  • Color: Black
