TITAN 172-C

TITAN 172-C

72x15 watts Cool White LED-City Wash

TITAN 172-C is a 72×15 watts Cool White LED city wash. It has high light efficiency, high illumination, high performance, and stability, it is realizable to achieve the perfect color interpretation and ultra-long light casting distance. Optional wireless DMX512 control, it provides diverse lighting solutions for a variety of large outdoor lighting projects, an ideal lighting fixture for towers, bridges, large venues, integrated commercial building, and other large occasions.

SKU: Titan172C Categories: ,

TITAN 172-C is a 72×15 watts Cool White LED city wash. It has high light efficiency, high illumination, high performance, and stability, it is realizable to achieve the perfect color interpretation and ultra-long light casting distance. Optional wireless DMX512 control, it provides diverse lighting solutions for a variety of large outdoor lighting projects, an ideal lighting fixture for towers, bridges, large venues, integrated commercial building, and other large occasions.

SOURCE

  • Light source: 72×15 watts Cool White
  • LED life expectancy: 50,000 Hrs
  • Peak Intensity: 2217600 cd (4°)

OPTICAL SYSTEM

  • Optics: 4°, 10° , 20°
  • Light output: 23,000 Lux @2m @ 4°

CONTROL & PROGRAMMING

  • Control Protocols: DMX
  • DMX control channels: 0-100% dimming
  • Controllable sections: 2
  • Color: Cool White

ELECTRICAL

  • Input Voltage: AC 100-240V, 50/60Hz
  • Max Power: 1200 W
  • Power Factor: > 0.9

CONNECTIONS

  • Power connection: 3m cable (input only)
  • Data connection: 3m cable (input + output)

PHYSICAL

  •  Dimensions: 881 x 252 x 569 mm
  •  Net Weight: 46 kg
  •  Color: Off White (Gray, Black Optional)
  •  Housing: Die-cast aluminum
  •  Security: Anti-thunder shock protection design
  •  IP Rating: 66
  •  Operation temperature: – 40°C~45°C (operating) /- 40°C~45°C (startup)
