WHOPPER 154-W

WHOPPER 154-W is a 54×3 watts Warm White high power LED exterior wash. It has an attractive and durable die-casting aluminum housing, built-in power supply and driver, and an independent heat dissipation system. It is equipped with adjustable glare shield, able to create an unparalleled lighting effect for the monuments, buildings, bridges and other architectural projects.

SKU: Whopper154W Categories: ,

WHOPPER 154-W is a 54×3 watts Warm White high power LED exterior wash. It has an attractive and durable die-casting aluminum housing, built-in power supply and driver, and an independent heat dissipation system. It is equipped with adjustable glare shield, able to create an unparalleled lighting effect for the monuments, buildings, bridges and other architectural projects.

SOURCE

  • Light source: 54×3 watts – Warm White
  • LED life expectancy: 50,000 Hrs
  • Peak Intensity: 146726cd (12°)

OPTICAL SYSTEM

  • Optics: 12° (5°, 12°, 45°)
  • Light output: 37,000 Lux  @2m @ 25°

CONTROL & PROGRAMMING

  • Control Protocols: DMX
  • DMX control channels: 0-100%
  • Controllable sections: 1
  • Color: Warm white

 ELECTRICAL

  • Input Voltage: AC100-240V, 50/60Hz
  • Max Power: 170 W
  • Power Factor: > 0.9

CONNECTIONS

  • Main connection: 3m cable(input only)
  • Data connection: 3m cable (input + output)

PHYSICAL

  • Dimensions: 354x283x450mm
  • Net Weight: 11 kg
  • Color: Black / Off White
  • Housing: Die-cast aluminum
  • IP Rating: 66
  • Operation temperature: – 40°C~45°C (operating) /- 20°C~45°C (startup)
