CPX 418OP

CPX 418OP

Outdoor 4 in 1 RGBW, LED Par

CPX 418OP is an 18 x 12 watts outdoor RGBW LED Par. Its heavy duty and robust built, with an IP65 rating, makes it the 1st choice multipurpose Par for all professional outdoor architectural and events application.

Add to wishlist
SKU: N/A Categories: ,

Videos

SOURCE

  • Light source: 18 x 12 watts, 4 in 1 RGBW LEDs
  • LED life expectancy: 50,000 Hrs.

OPTICAL SYSTEM

  • Beam angle: 25°
  • Light output: 7,000 Lux @ 2m @ 10°

DYNAMIC EFFECTS

  • Dimmer: 4 selectable dimming curves
  • Color mixing: RGBW
  • Strobe and fade effect
  • Built-in color and dynamic macros

CONTROL & PROGRAMMING

  • Control protocols: DMX, Master-Slave, Auto Run
  • Display : TFT displayer with 4 buttons
  • Control channels: 3, 4, 6, 8, 11 CHs

 ELECTRICAL

  • Input voltage: 100-240V/50-60Hz
  • Power consumption: 230 watts

 CONNECTIONS

  • DMX connections: IP DMX In/Out cables with 3 pin screw lock connectors
  • Power connections: IP Power In/Out cable, screw lock connectors

 PHYSICAL

  • Dimensions: 280.32 x 142.56 x 288.28mm
  • Net weight: 5 Kg
  • Color: Black
  • Housing: Aluminum
  • IP rating: 65
  • Operating temperature: -20°C/45° C
Housing Color

Black Housing, White Housing
