SOURCE
- Light source: 88 x 20 watts, RGBW LEDs
- LED life expectancy: 50,000 Hrs.
- CRI <80
OPTICAL SYSTEM
- Beam angle: 20°
- 40° with a magnetic diffuser filter
- Light output: 146000 Lux @ 2m @ 20°
- Individual angle rotation adjustment for each head
DYNAMIC EFFECTS
- Dimmer: 4 selectable dimming curves
- Color mixing: RGBW
- Strobe effect
- Built-in effects
CONTROL & PROGRAMMING
- Control protocols: DMX, Master-Salve, Auto Run W-DMX™ by Wireless Solution
- Display: TFT displayer with 4 buttons
- Control channels: 2, 3, 4, 9, 12 CHs
ELECTRICAL
- Input voltage: 190-264V/50-60Hz
- Power consumption: 1600 watts
- Power supply: Auto-ranging electronic switch-mode
CONNECTIONS
- DMX connections: 3 pin XLR In/Out male and female
- Power connections: IP Power In/Out cable
PHYSICAL
- Dimensions: 602 x 430 x 437mm
- Net weight: 23.5 Kg
- Color: Black
- Painting: Anti-salt and Anti-UV
- Housing: Die-cast Aluminum
- IP rating: 65
- Operating temperature: -40°C/45°C
