LEDE 200 SPOT

LEDE 200 Spot is a super bright LED moving head with unique 150 watts LED source, projected from a compact tiny body.

SKU: LEDE200S Categories: ,

SOURCE

  • Light source: 150 watts white LED
  • LED life expectancy: 50,000 Hrs.

OPTICAL SYSTEM

  • Beam angle: 14°
  • Light output: 25,700 Lux @ 10m @ 14°

DYNAMIC EFFECTS

  • Dimmer: 0-100% linear adjustment
  • Color wheel: 8+ Open colors indexable and bidirectional rainbow effect
  • Static gobo: 7 gobos + open
  • Rotating gobo: 7 gobos + open, interchangeable position
  • Prism: Rotating effect wheel with 3 facets, 8 facets prism and frost
  • Fast speed iris

CONTROL & PROGRAMMING

  • Control protocols: DMX, RDM
  • Display: 4’ colored LCD display, can reverse 180°
  • Control channels: 21, 24, 14, 16 CHs

MOVEMENT

  • Pan: 630o
  • Tilt: 265o
  • Resolution: 16 bit

ELECTRICAL

  • Input voltage: 100-240V/50-60Hz
  • Power consumption: 250 watts
  • Power supply: Electronic auto-ranging

CONNECTIONS

  • Power connections: Neutrik Powercon In/Out

PHYSICAL

  • Dimensions: 343 x 262 x 455mm
  • Net weight: 15 Kg
