SOURCE
- Light Source: 48 x 8W RGBL LEDs
- Light Output: 7,040 lm (all LEDs on)
- Illuminance: 14,136 Lux @ 2m | 2,262 Lux @ 5m | 883 Lux @ 8m | 565 Lux @ 10m
- LED Life Expectancy: 50,000 h
- Color Temperature: 1800K to 10000K
OPTICAL SYSTEM
- Beam Angle: 30×70˚ (average)
- Field Angle: 60×120˚ (average)
MOVEMENT
- Tilt: 0-120° (Manual adjustment)
COLORS
- Color Mixing: RGBL
- White Balance: Adjustable Red, Green, Blue, and Lime (127-255)
DYNAMIC EFFECTS
- Dimmer: 0-100% linear adjustment
- Strobe: 0-20 Hz adjustable; includes Random, Pulse, Fade Up, and Fade Down strobe effects
- Pixel Mapping: 6 controllable sections or 12 individual LED segments depending on DMX mode
CONTROL & PROGRAMMING
- Display: LCD Touch Screen
- Control Channels: 1, 4, 11, 18, 22, 48, 58 CH
- Control Protocols: DMX-512, RDM, Master/Slave, Auto Run (31 programs), Wireless CRMX, and Vision App control
- Dimming Curves: 4 selectable curves (Linear, Square Law, Inv Square Law, S-Curve)
- Dimmer Response: 4 selectable speeds plus Halogen effect mode
- PWM Frequency: Selectable 600Hz, 1200Hz, 2400Hz, 4800Hz, 12000Hz, 25000Hz for flicker-free performance
- Color Macros: 51 selectable colors
THERMAL MANAGEMENT
- Operating Temperature: -40°C to 40°C
- Maximum Housing Temperature: Up to 55°C during normal operation
- Temperature Monitoring: Real-time temperature display on LCD with over-temperature yellow/error alerts
CONNECTIONS
- Power Connections: PowerCON TRUE1 In/Out, 3-pin XLR DMX In/Out
BATTERY
- Battery Capacity: 14.8V, 27AH
- Battery Usage: Selectable run times: Battery Boost, 4H, 6H, 8H, 10H, 12H, 14H, 16H, 18H, 20H, 22H, 24H
- Battery Charge Time: 5 hours
ELECTRICAL
- Input Voltage: AC100-240V – 50/60Hz
- Power Consumption: 103W
PHYSICAL
- Dimensions: 399 x 140 x 270 mm
- Weight (N.W.): 10.11 kg
- IP Rating: IP65
- Rigging: Hanging panel with fast-lock capability and safety rope hole
ACCESSORIES
- Optional Accessories: Magnetic frost filter, one-sided barndoor, four-sided barndoor
