CONTROL & PROGRAMMING
- Default IP:192.168.1.1OO
- Default Subnet: 255.255.255.0
- Input protocol: Artnet
- Output protocols: DMX, 40 FPS
- Control channels: 8×512 CHs
ELECTRICAL
- Input voltage: 100-24OV 50/60Hz
- Power (out): 24V / 1000 watts
CONNECTIONS
- Ethernet port: RJ 45
- Output port: 4 Pin DMX+24VDC
PHYSICAL
- Dimensions: 483 x 330 x 89mm
- Rack Size: 2U
- Color: Black
- IP: 20
