SOURCE
- Light source: 400 watts
- Lamp life expectancy: 1,500 Hrs.
OPTICAL SYSTEM
- Beam angle: 4° and 6°
- Light output: 390,000 Lux @ 10m @ 4°
- Electronic focus
DYNAMIC EFFECTS
- Dimmer: Linear adjustment
- Color wheel: 14 colors + open
- Electronic variable strobe
- Static gobo: 14 gobos + open
- Gobo shake function
- Prism 1: 16 facet prism – 6 linear facet prism – Frost
- Prism 2: 32 facet prism – 6 linear facet prism – 1 double prism (6+12)
- Prism are combinable with independant rotation
CONTROL & PROGRAMMING
- Control protocols: DMX
- Display: 2.8’ full color touch screen, reversible 180°
- Control channels: 16, 19 CHs
MOVEMENT
- Pan: 540°
- Tilt: 280°
- Resolution: 16 bit
ELECTRICAL
- Input voltage: 100-240V/50-60Hz
- Power consumption: 600 watts
CONNECTIONS
- DMX connections: 3 pin and 5 pin XLR In/Out male
and female - Power connections: PowerCon In
PHYSICAL
- Dimensions: 410 x 350 x 592mm
- Net weight: 20 Kg
- Color: Black
- IP rating: 20
