SOURCE
- Light Source: 64 x 8W RGBL LEDs
- Total Output: 10,937 Lm
- Color Temperature: 12,000K (at full)
- Illuminance: 3,085 lx @ 2m | 490 lx @ 5m | 122 lx @ 10m
OPTICAL SYSTEM
- Beam Angle: 60˚ x 20˚ (Native)
- Spot Angle: 85˚ x 25˚
- Lens Type: AP04-long strip lens
- Filters: Frost filter available
MOVEMENT
- Tilt: 0˚ – 90˚ manual adjustment
COLOR
- Color Mixing: RGBL (Red, Green, Blue, Lime).
- Color Macros: 51 pre-programmed color macros.
- CTO: 2,700K to 8,000K (linear)
- White Balance: Manual adjustment for Red, Green, Blue, and Lime
DYNAMIC EFFECTS
- Strobe Effect: 0 – 20Hz adjustable
- Pixels: 16 independent control sections
- Fade Effect: Adjustable fade speed for auto programs
CONTROL & PROGRAMMING
- Display: LCD Touch Screen with 4-button navigation
- Control Channels: 3 / 4 / 8 / 12 / 16 / 17 / 25 / 32 / 64 / 73 CHs
- Control Protocols: DMX-512, Master/Slave, Auto Run
- Dimming Curves: 4 selectable dimming curves (Linear, Square Law, Inv. Square Law, S-Curve)
- Dimmer Speed: 5 selectable dimmer speed levels
- LED Frequency: Selectable PWM (1KHz to 18KHz)
- Programs: 31 built-in Auto Modes
THERMAL MANAGEMENT
- Operating Temperature: -40˚C / 45 ˚C
- Temperature Control: Smart monitoring with Max Temp range 30˚C – 70˚C
CONNECTIONS
- Power Connections: Power In and Power Out (True One power cable included)
- DMX Connections: 3-pin (or 5-pin via adapter) XLR In/Out
ELECTRICAL
- Input Voltage: 100-240V / 50-60Hz
- Power Consumption: 160W
- Luminous Efficacy: 72.3 lm/W
PHYSICAL
- Dimensions: 1005 x 174 x 140 mm.
- Net Weight: 7.5 Kg
- IP Rating: IP65
- Installation: Sliding stand and splicing system with positioning blocks
