SOURCE
- Light Source: 19x40W RGBL LED
- Output: 11,100 lm
- Illuminance: 16000 lux @ 10m @6°
- LED Life Expectancy: 20,000 Hrs.
OPTICAL SYSTEM
- Lens: Bi-directional rotating front lens
- Beam Angle: 6° to 36°
COLORS
- Color mixing: RGBL
DYNAMIC EFFECTS
- Kaleidoscope effect
- Dimmer: 0-100% Linear dimming
- Strobe: Electronic variable strobe
- Built-in color and dynamic macros
- Pixels: Pixel-by-Pixel control
CONTROL & PROGRAMMING
- Display: 1.7-inch LCD color screen
- Control Protocol: DMX/RDM
- Control Channels: 21, 23, 35, 78, 92, 97, 99 CHs
MOVEMENT
- Pan: 540°
- Tilt: 270°
- Resolution: 16 bit
ELECTRICAL
- Input voltage: 100-240V / 50-60HZ
- Power Consumption: 800W:
- Power Factor: PF＞0.95
CONNECTIONS
- Power connections: PowerCon In/Out male and female
- DMX connections: 3 pin and 5 pin XLR In/Out male and female
PHYSICAL
- Dimensions: 335 x 280 x 470 mm
- Net Weight: 18.5 kg
- Housing Color: Black
- IP Rating: IP65
