SOURCE
- Light Source: 7 x 20 watts RGBW LEDs
- Illuminance: 2232 lx (15˚ at 5m) | 558 lx (15˚ at 10m)
- LED life expectancy: 50,000 hr
OPTICAL SYSTEM
- Beam Angle: 15°
DYNAMIC EFFECTS
- Color Mixing: RGBW
- Strobe and fade effect
- Built-in color and dynamic macros
CONTROL & PROGRAMMING
- Display: TFT displayer with 4 buttons
- Control Channels: 3, 6, 8 , 10, 13 CHs
- Control Protocols: DMX, Master-Slave, Auto Run
- Dimming Curves: 4 selectable dimming curves
ELECTRICAL
- Input Voltage: AC100-240V / 50-60Hz
- Power Consumption: 90W
CONNECTIONS
- DMX Connections: IP DMX In/Out cables with 3 pin screw lock connectors
- Power Connections: IP Power In/Out cable, 3 pin screw lock connectors
PHYSICAL
- Dimensions: 219 x 113 x 225 mm
- Net weight: 3.4 Kg
- Housing: Aluminum
- Housing Color: Black
- IP Rating: IP65
- Operating Temperature: -30°C/45°C
