FR 100-W

FR-100W is a 100 watts 3200K Warm white LED Fresnel with motorized zoom. It is RDM-DMX compliant, 25° to 65° motorized zoom along with its superior 96 CRI. A barn door is included to shape the light.

SKU: FR100W Categories: ,

SOURCE

  • Light source: 100 watts Warm white COB LED
  • Color temperature: 3200K
  • LED life expectancy: 50,000 Hrs.
  • CRI: 96
  • TLCI: 98

OPTICAL SYSTEM

  • Electronic zoom
  • Zoom range: 25° to 65°
  • Light output: 2,000 Lux @ 4m @ 25°

KEY FEATURES

  • 5 Dimmer curves
  • Strobe
  • Video flicker free with selectable PWM
  • Silent operation
  • PMMA polymethyl methacrylate lens
  • Barn doors included

CONTROL & PROGRAMMING

  • Control protocols: DMX, RDM
  • Control channels: 2, 3, 4, 5 CHs

 ELECTRICAL

  • Input voltage: AC100-240V/50-60Hz

CONNECTIONS

  • DMX connections: 3 pin XLR In/Out male and female
  • Power connections: PowerCon In/Out

PHYSICAL

  • Dimensions: 295 x 275 x 345 mm
  • Net weight: 5.8 Kg
  • Color: Black,
  • Housing: Aluminum
  • IP rating: 20
  • Operating temperature: -5°C/45°C
