LEDE 300-S

LEDE 300-S is a 300 watts LED moving head with spot, wash, and animation effect. This LED moving head delivers a powerful output along a wide variety of output and creative effects which makes it  perfect  for large venues and entertainment applications.

SKU: LEDE300S Categories: ,

Videos

SOURCE

  • Light source: 300 watts white LED
  • LED life expectancy: 50,000 Hrs.
  • Color temperature: 6600K
  • CRI 70

OPTICAL SYSTEM

  • Beam angle: 13° to 44°
  • Light output: 60,000 Lux @ 2m @ 13°
  • Electronic focus

DYNAMIC EFFECTS

  • Dimmer: linear adjustment
  • Electronic variable strobe
  • Color wheel: 7 colors + open
  • Effect color wheel: 6 colors
  • Static gobo: 8 gobos +open
  • Rotating gobo: 7 gobos + open
  • Gobo shake function
  • Animation wheel: 3 continuous bi-directional rotation animation wheel
  • Prism: 3-facet circular prism
  • Iris
  • Frost filter

CONTROL & PROGRAMMING

  • Control protocols: DMX, Auto program, Master slave
  • Control channels: 20, 25 CHs

MOVEMENT

  • Pan: 540o
  • Tilt: 270o
  • Resolution: 16 bit

ELECTRICAL

  • Input voltage: 100-240V/50-60Hz
  • Power consumption: 300 watts

CONNECTIONS

  • DMX connections: 3 pin XLR In/Out male and female
  • Power connections: PowerCon In

PHYSICAL

  • Dimensions: 369 x 292 x 599mm
  • Net weight: 18.6 Kg
  • Housing: Plastic
  • Color: Black
  • IP rating: 20
