SOURCE
- Light source: 320×0.5W RGB+Mint+Amber LED
- Output:
– Light output all LEDs on: 572 lm
– Light output red:70 lm
– Light output green:358 lm
– Light output blue:70 lm
– Light output Amber:402 lm
– Light output Mint:172 lm
- Illuminance:
– Lux @ 2m:48 lx
– Lux @ 5m:8 lx
– Lux @ 8m:3 lx
– Lux @ 10m:2 lx
- LED Life expectancy: 50,000 hours
OPTICAL SYSTEM
- Beam angle: 135×115°
- Field View angle: 175×160°
DYNAMIC EFFECTS
- Dimmer: 0-100% linear adjustment
- Four dimming curves
- 16 Pixel control
- Color mixing: RGB+Mint+Amber
- Color temperature adjustments: 1750 to 20000K
- Electronic Strobe: 0-20 Hz
CONTROL & PROGRAMMING
- Control Protocols: DMX/RDM, CRMX Wireless DMX, iOs/Android/Windows Application control, Remote control, Manual
- Channel mode: 2, 3, 5, 10, 12, 20, 40, 80, 85 channels
- Display: LCD
BATTERY
- Battery Life: Up to 14H
- Multiple battery usage option: Battery Boost/4H/6H/10H/14H
- Battery charge time: 4H
ELECTRICAL
- Input voltage Rating: DC 18V-20V
- Maximum Power consumption: 88W
- LED PWM Frequency: 600/1.2K/2.4K/4.8K/12K/18K (hz)
PHYSICAL
- Material: Aluminum/PC
- IP Rating: 65
- IK Rating: IK07
- Operating Temperature: -20°~50°C
- Humidity: 98%
- Dimensions: 1060 x 44 x 44 mm
- Weight: 1.2 Kg
