SOURCE
- Light source: 19x60W RGBL LEDs
- Auxiliary source: 76×0.5W RGB LEDs
- Life expectancy: up to 50,000 hours
- CRI: Ra> 80
OPTICAL SYSTEM
- Beam angle: 4.5˚ to 60˚
- Motorized Zoom
DYNAMIC EFFECTS
- Color Mixing: RGBL and Pixel Control
- Secondary Effect: RGB Spark LED Lens Effect
- Color Temperature: 2000K – 8000K (Linear Presets)
- Color Presets: Built-in Presets and Macros
- Dimming: 16-bit Dimming and Variable Curves
- Electronic Strobe
CONTROL & PROGRAMMING
- Display: LCD display (4 touch button control panel)
- Control channels: 26, 98, 251, 321 Chs
- Protocols: DMX, RDM, Art-Net, sACN
MOVEMENT
- Pan: 540°
- Tilt: 210°
- Resolution: 8/16 bit
- Position correction system
ELECTRICAL
- Input voltage: 100-240V / 50-60Hz
- Power consumption: 1500W
CONNECTIONS
- DMX connections: IP65 5pin XLR In/Out
- Power connections: IP65 power connector In/Out
- Network connections: IP65 RJ45 Ethernet In/Out
PHYSICAL
- Dimensions: 430 × 280 × 514 mm
- Net weight: 23 Kg
- Operating temperature: −20˚C / 45˚C
- IP rating: IP65
