SPO 516

5 Pin Outdoor Weatherproof Wireless DMX Splitter

SPO 516 is a die-casted Aluminum outdoor DMX Splitter. It splits, boosts and distributes the DMX signal through 6 optically isolated outputs, preventing any signal distortions or disturbance. Each port is equipped with a waterproof cap. It is designed to be installed outdoor for a convenient data distribution structure for fixed installations and events.

SKU: SPO516 Category:


  • Split and boost the DMX signal
  • Power and data optically isolated DMX ports
  • High voltage protection
  • High brightness Power and DMX Status LED indicators
  • Weatherproof and UV resistant
  • Waterproof cover on each port


  • DMX Pass-Thru
  • Termination on/off switch
  • Power and Data LED indicators


  • Data inputs: 1 x 5 pin XLR
  • Data thru: 1 x 5 pin XLR
  • Data outputs: 6 x 5 pin XLR
  • Power input: IP Power Connector


  • Input Voltage: AC 88-256V 50/60 Hz


  • Dimensions: 234 x 166 x 84 mm
  • Net Weight: 2.2 Kg
  • Color: Grey
